Forklift Truck
Forklift Truck Model FD 30M1
Forklift Trucks are being manufactured under license from Anhui Forklift Truck Group (Heli) which is based on TCM technology Japan and power by world renowned D3.1524 engine (Manufactured under Perkins (UK) Technology).
Salient Features:
.
Low cost of ownership, low cost of operation and high quality are the key features of our FD30M1 Forklift Truck.
.
The Controls are simple and conveniently placed so the driver’s concentration can be on the job and not on mastering the machine.
.
The hydraulic levers give positive “feel” of the hoist and tilt function to aid precise load control.
.
The D3.1524 engine fitted is the most economical, highly efficient and requires minimum maintenance with easy availability of parts upto town level.
.
Prompt after sales services and support to our valued customer.
Technical Specifications:
Characteristics
Manufacturer
.
Millat Tractors Limited
Model
.
FD30M1
Load Capacity
Kg
3000
Load Center
mm
500
Power Type
.
Diesel
Control Type
.
Sit Down Rider Type
Tyre Type
Front / Rear
.
Pneumatic
Wheels(x = driven)
Front / Rear
.
2 x 2
.
Dimensions & Weight
Maximum Fork Height
mm
3000
Free Lift
mm
305
Fork Size
L x W x T
mm
1070 x 125 x 45
Tilt Angle
Fwd / Bwd
deg
6 / 12
Length to Fork Face
mm
2693
Overall Width
mm
1225
Mast Height Fork Lowered
mm
2070
Overhead Height Fork Raised
mm
4250
Overhead Guard Height
mm
2090
Turning Radius (Outside)
mm
2400
Load Distance (Centerline of front axle to front face of forks)
mm
498
Basic Right Angle Stacking Aisle Width (Add load length and clearance)
mm
2898
Total Weight
Kg
4400
.
Performance
Speeds
Travel Max.(Fwd / Rvs)
With Load
km/h
15.3
Without Load
km/h
16.5
Lifting
With Load
mm/s
335
Without Load
mm/s
385
Lowering
With Load
mm/s
450
Without Load
mm/s
500
Max. Drawbar Pull
With Load
kg
1500
Without Load
kg
1000
Max. Gradeability
With Load
%(tone)
18
Without Load
%(tone)
20
.
Chassis
Tyre
Number
Front / Rear
.
2 / 2
Size
Front
.
28 x 9 -15 - 12 PR
Rear
.
6.50 - 10 - 10 PR
Wheel Base
mm
1700
Tread
Front
mm
1000
Rear
mm
970
Ground Clearance
At Lower Point (Mast)
mm
135
Frame
mm
140
Brake
Service
.
Hydraulic - Foot Pedal
Parking
.
Mechanical - Hand Lever
.
Engine & Transmission
Battery
Voltage
V
12
Capacity
Ah
96
Internal Combustion Engine
Model
.
D9.1524
Rated Horsepower at 2,250 rpm
Ps /hp
50.7 / 50.0
Maximum Torque at 1,400 rmp
Nm
172
Number of Cylinders
.
3
Displacement
lit
2.5
Fuel Tank Capacity
lit
50
Transmission
Number of Speed Fwd/Rvs - Type
.
2 / 2-Manual Shift
Operating Pressure
For Attachment
kg/cm2
175
.
Note
Products and Specifications are subject to change without prior notice.
